Drilling fluid sand mud removal machine is used for drilling fluid solids control system of 2/3 solids control equipment, drilling fluid sand silt is all-in-one hydrocyclone desanding/mud, with a combination of vibrating screen, a drilling fluid sand silt all-in-one work reliable maintenance convenient, can effectively remove the suspended more than 30 microns in drilling fluid solid phase particles, increase drilling fluid to realize the barite recovery and increase the use requirements of the drilling fluid, drilling fluid performance, stable to improve drilling efficiency, reduce drilling cost, drilling fluid sand mud removal machine is the ideal equipment of drilling fluid separation oil industry.
Drilling fluid shale shaker sand mud removal machine adopts special flameproof vibration motor as vibration source, compact structure, high efficiency, safe and reliable.Drilling fluid sand silt all-in-one desanding hydrocyclone, in addition to the mud cyclone to choose suitable for outdoor + 40 ℃ efficient polyurethane materials.Drilling fluid desanding desanding and desilting machine desilter cyclone parts not adhering sand, wear resistance, corrosion resistance, light installation, etc.
Vibrating screen is at the bottom of the drilling fluid sand silt machine according to the theory of linear motion track vibration sieve surface design, two motor midperpendicular Angle and screen surface into a corner, such two vibrating motors rotating in opposite directions, the mutual movement generated excitation power, offset each other in the X direction, vibration force is zero.And two motors in Y direction vibration force each other to drive the whole the reciprocating movement of the screen box up and down along the Y direction, at the same time make the mud on the surface of the mesh along the Y direction is thrown, then free fall has been moving forward, so being thrown down on the mud forward movement, mud slurry leaking through the sieve into the mud tank and the most solid particles in the mud is screening out, thus the mud slurry purification effect.
Drilling fluid sand silt on the integrative cyclone is designed according to the principle of particle sedimentation, the drilling fluid separation medium through sand pump produce certain pressure and velocity, along the spiral into the cyclone wall, coarser particles under the action of centrifugal force and gravity, the cyclone wall spiral sink, from the bottom LiuKou eduction, falls below breakdown vibrating screen separation, has risen in a spiral along the hydrocyclone, the rest of the media from the overflow mouth into the next level of separation device further purification treatment.tumblr_merk9lMF7B1qmbqy4
